Wrapping Process
suitable for medicines, health products, food, cosmetics, tobacco and so on industry, as the cluster packing for small box and replace middle box, particularly suitable for high quality packaging requirements of medicines and health products, is one of the newest generation of ideal packaging machinery products.
This product can automatic feeding box, stacking, packing, sealing, sorting, counting, and selfadhesivesecurity cable. It uses transparent paper film completely wrapped on the outside of the product in the appearance of the full display items, increase beauty and value sense, increase the sale of products at the same time, to ensure that the packaging of goods is sealed, moisture-proof, anti pollution. The instant sealing technology, which is a national initiative.
PLC Control System
Quick Changeover System
Cam Drive
Side Loading Film Spindle
Features
- Fully sealed packaging: waterproof, moisture, anti pollution.
- Instant sealing, heat sealing position does not store material: approximate cold packaging, the product has no effect on drug products.
- Selfadhesivesecurity cable: improve product anti-counterfeiting ability.
- Automatic feeding, automatic stacking, packing, sealing, sorting and counting.
- Adopts PLC programmable controller to make the whole machine programmed.
- Automatic zero, reset function, equipment is more humanized and intelligent, use, operation, maintenance, maintenance simple.
- Packing speed can stepless speed regulation, to replace the folding board and a few parts can be packaged for different specifications (size, height, width) of the cassette packaging.
- The packing speed, high efficiency and energy saving.
Specifications
| Model | DTS-450 |
|---|---|
| Packing Speed | 10-40 PCS/MIN |
| Packing Size | L: 90-300mm; W: 60-240mm; H: 40-90mm |
| Packing Material | BOPP Film, PVC |
| Voltage Supply | 380V 50/60HZ |
| Total Power supply | 4.0KW |
| Working Pressure | ≥0.6mpa 20m3/h |
| Overall Dimension | (L)2500×(W)800×(H)1200mm |
| Machine Weight | 800KG |
